江苏江日照明 · 防爆灯系列The product description

防爆灯系列

应用场景/Application scenario

本产品具有良好的防爆功能,适用于IIA、IIB、IIC类爆炸性气体环境和各种易燃易爆场所,主要应用于铁路、电力、冶金、石油、石化、化工、钢铁、航空、船舶及各类厂区、场站、大型设施、场馆等场所的高效照明。

This product has good explosion-proof function, suitable for IIA, IIB, IIC explosive gas environment and various inflammable and explosive places, mainly used in railway, electric power, metallurgy, petroleum, petrochemical, chemical, steel, aviation, ship and each Efficient lighting in factories, stations, large facilities, venues and other places.

产品特性/Product Features

(1)配置:采用进口LED光源,平均使用寿命长达10万小时,电源采用宽电压处理,能实现恒流输出,具有短路、过压保护功能,大大延长了灯具的使用寿命。

(2)散热散热器采用一体式流线型结构方式,更好的增加了热传导,散热片采用内外圆周阵列方式排列,提高散热性能。

(3)防眩:钢化玻璃罩(透明和磨砂两种选配方式),抗冲击,防眩光,使灯光均匀柔和无暗影,透光率高达95%-98%,适合各种低顶,平台,高顶、高棚等场所作为固定照明使用。

(4)防护:灯体的防护等级为IP66,防腐等级可达到WF2,灯体表面不腐蚀,不生锈。

(5)安装方式:可根据需要采用吊顶、弯杆,立杆,吸顶,U型防震支架(角度可调)等多种安装方式。

(6)进线口:采用双进线口设计可实现灯具的串联并接安装方式。

(1) Configuration: Using imported LED light source, the average service life is as long as 100,000 hours. The power supply adopts wide voltage processing, which can realize constant current output, has short circuit and over voltage protection functions, and greatly prolongs the service life of lamps and lanterns.

(2) The radiator adopts an integrated streamlined structure, which can better increase the heat conduction. The radiator is arranged in an internal and external circular array to improve the heat dissipation performance.

(3) Anti-glare: toughened glass cover (transparent and frosted two options), anti-impact, anti-glare, so that the light uniform and soft without shadows, transmittance up to 95% - 98%, suitable for all kinds of low-roof, platform, high-roof, high-roof and other places as fixed lighting.

(4) Protection: The protection level of the lamp body is IP66, and the anti-corrosion level can reach WF2. The surface of the lamp body will never corrode and rust.

(5) Installation mode: Suspension ceiling, bending rod, vertical rod, suction top, U-shaped shock-proof bracket (angle adjustable) and other installation modes can be adopted as required.

(6) Inlet port: Series and parallel connection of lamps and lanterns can be realized by adopting double inlet design.

防爆灯系列 · 产品展示The product display
